Home > Products > Portable Ventilator > BiPAP Machine

OLV-DS8 BiPAP Machine For Home Use

Model Number: OLV-DS8

Standard Configuration: BiPap Machine and Accessories

Product highlight: Efficient Carbon Emission, Resistance Control, One-Click Startup, Multiple Parameters Displayed in Real-time

Product features: fast, convenient, quiet, comfortable, etc.

Function: Treat lung diseases and sleep apnea treatment.

Customization: Customized packaging, Customized logo, Graphic customization


For business OEM/ODM bulk sales service, please inquire us right now.


Product Details

Medical Portabl CPAP/ST Mode Bipap Machines For Obstructive Sleep Apnea therapeutic Devices/Auto cpap Bipap Machine For Home Use. Olive focuses on the production and development of medical products. We Are the Professional BIPAP/CPAP Manufacturer. Welcome to contact us for long term cooperateion whenever possible.


OLV-DS8 BiPAP Machine For Home Use

Why is Bi-level BiPAP More Comfortable?

Double level means double airway pressure, can set higher pressure and lower expiratory pressure,The bi level BiPAP is a more comprehensive dual airway pressure ventilator, which can be set with a higher inspiratory pressure and a lower expiratory pressure, respectively. The machine provides a higher inspiratory pressure when the patient is inhaling To keep the airway open, provide low exhalation pressure when exhaling to ensure that the patient's breathing is smooth


Do you know what is Respiratory Insufficiency?

 External respiratory function is severely obstructed, making the arterial blood oxygen content below the normal range (partial blood oxygen pressure <8kpa) accompanied by an increase in partial carbon dioxide pressure (partial carbon dioxide pressure <6.67KPA), and a series of pathological processes with symptoms and signs.


 Mainly applicable to the following conditions

1.Difficulty breathing,

2.OSA (Obstructive sleep apnea),

3.CSA (Central sleep apnea),

4.MSA (mixed sleep apnea),

5.COPD (chronic obstructive pulmonary disease, chronic obstructive pulmonary disease).

Moderate to mild respiratory failure, pulmonary function, respiratory insufficiency, severe sleep respiratory syndrome

BiPAP Machine For Home Use

Product Specification

OLV-DS8 BiPAP Machine For Home Use

OLV-DS8 BiPAP Machine For Home Use

Model Number

OLV-DS8

Screen

2.8 inch TFT, 320 x 240

Work Mode

CPAP, Auto, S, T, ST, APCV

APCV mode assured Tidal Volume

delivery using pressure support

ColorGrey

Data Storage

SD Card
Power SupplyInput 100-240V, 50-60HZ, 1-2A, Output + 24V, 2.5A

DC Voltage

24VDC, 2.5A
Over-Temperature ProtectionStop  automatically, alarm with 4 times
Lock FunctionYes
Screen Auto SleepAuto sleep in 15 minutes, press any button to highlight screen
Backup Rate5-50/min, adjustable
I/E10-80%
Ramp Item0-60min adjustable 1min/Step
Auto ON/OffYES

Sound

28db
Pressure Range4-25cmH2O         4-30cmH2O

IPAP

4-25 cmH2O        4-30 cmH2O
EPAP4-20 cmH2O        4-20 cmH2O

Ramp Item

0-60min adjustable 1 min/Step

Inspirate Triggle

1-5 Level
EPRYes, 0-3 level
Water Capacity220ml max
Humidifier LevelIntegrated Heated,0-5 level
Alarm Power off, mask off
Dimensions(cm)
28Lx14Wx9.5H(machine); 38.5Lx36.5Wx16H(1pc carton)
Weight(with humidifier)1.6Kg(net weight); 3.9Kg(gross weight)
Accessories

Integrated heated humidifier, Water tank, Power lead, Travel bag,

User manual, Air filter, SD card, Full face mask, Air tubing, Software


Product Feature

 1. 2.8”TFT LCD display with easy operation.

 2. Interactive operation interface is available. Back-lighting function allow night operation.

 3. Fashionable design with fine piano lacquer, convenient for wipe.

 4. Respiratory waveform & quality waveform display can achieve real time monitoring of CPAP

 5. Ultra silent design & Delay time step up design.

 6. The portable machine adopts imported movement technology, capable of constant heating.

 7. Bipap machine is working to achieve human-computer synchronization.

OLV-DS8 BiPAP Machine For Home Use

Product Advantages


1.EFFICIENT CARBON EMISSION

Mak The Mask More Fit, Breathing Is Guaranteed,Resistance control to ensure which type of mask can be used to ensure pressure transmission and enjoy the comfortable experience brought by the machine

BiPAP Machine For Home Use

2.RESISTANCE CONTROL

High breathing ratio, equipped with powerful pressure of 20PHA, quickly remove carbon dioxide from the body

BiPAP Machine For Home Use

3.ONE-CLICK STARTUP

More Intuitive Operation And Easier Use

BiPAP Machine For Home Use

4.Multiple Parameters Displayed in Real time

Multiple Parameters Displayed in Real Time to check the treatment effect in time.and the english menu is more convenient to operate

BiPAP Machine For Home Use

BiPAP Machine For Home Use
